ASTM A213 4 Inch SCH40 Alloy Steel Seamless Pipe Plain End

Key Specifications / Features

Model no.: HX- Alloy Steel Seamless Pipe-37 Hits: 10

China manufacturer of ASTM A213 4 Inch SCH40 Alloy Steel Seamless Pipe Plain End

Request a quote share

Detail Information

Standard&material: ASTM A213 T5,T9,T11,T12,T22 and equivalent standard&material like ASTM A335 P5,P9,P11,P12,P22 etc.
Size range: 12.7mm*1.2mm-168mm*18mm
Manufacture method: Cold rolled, cold drawn, hydraulic cold drawn
Delivery condition: Normalized+tempered.
Packing: In bundles tied with steel strips. Oil coating, end plastic caps.
End finish: plain ends with square cuts.
Size tolerance: as per ASTM A450
Which is widely used in Steel Boiler, Superheater, and Heat-Exchanger etc high pressure & temperature environment.

Standard	Grade	Chemical Composition (%)							Mechanical Properties
Standard	Grade	C	Mn	P	S	Si	Cr	Mo	Tensil Strength Mpa min	Yield Strength Mpa min	Elongation % min
A213	T5	0.15 max	0.30–0.60	0.025 max	0.025 max	0.5 max	4.00–6.00	0.45–0.65	415	205	30
	T9	0.15 max	0.30–0.60	0.025 max	0.025 max	0.25–1.00	8.00–10.00	0.90–1.10	415	205	30
	T11	0.05–0.15	0.30–0.60	0.025 max	0.025 max	0.50–1.00	1.00–1.50	0.44–0.65	415	205	30
	T12	0.05–0.15	0.30–0.61	0.025 max	0.025 max	0.5 max	0.80–1.25	0.44–0.65	415	220	30
	T22	0.05–0.15	0.30–0.60	0.025 max	0.025 max	0.5 max	1.90–2.60	0.87–1.13	415	205	30
A335	P5	0.15 max	0.30–0.60	0.025 max	0.025 max	0.50 max	4.00–6.00	0.45–0.65	415	205	30
	P9	0.15 max	0.30–0.60	0.025 max	0.025 max	0.25–1.00	8.00–10.00	0.90–1.10	415	205	30
	P11	0.05–0.15	0.30–0.60	0.025 max	0.025 max	0.50–1.00	1.00–1.50	0.44–0.65	415	205	30
	P12	0.05–0.15	0.30–0.61	0.025 max	0.025 max	0.50 max	0.80–1.25	0.44–0.65	415	220	30
	P22	0.05–0.15	0.30–0.60	0.025 max	0.025 max	0.50 max	1.90–2.60	0.87–1.13	415	205	30
