SS316 8Inch Sch40 Seamless Stainless Steel Pipe
Key Specifications / Features
Model no.: HX- stainless steel pipe-18 Hits: 16
China manufacturer of SS316 8Inch Sch40 Seamless Stainless Steel Pipe
Request a quote
share
Tags
Detail Information
Standards: ASTM(ASME) (SA)A312/213/376 etc
Manufacturing method: Cold drawn, hot rolled ,ERW
Surface finish: Anneal/pickling/manual polished/ mechanical polished
Material: TP304/304L/H/LN, TP309S/310S, TP316/316L, TP317/317L, TP321/321H, TP347/347H, TP316Ti, TP904L, N08904, S31803, S32205, S32304, S32750, SAF2205, SAF2304, SAF2507, 1.4301, 1.4306, 1.4401, 1.4404, 1.4833, 1.4845, 1.4571, 1.4438, 1.4541, 1.4550, 1.4539, 1.4462 1.4410, 12X18H10T, 08X18H10T and so on.5) 6) Size:
NPS: 1/8" to 20"
Schedule: 5/5S, 10/10S, 20/20S, 40/40S, 80/80S, 120/120S, 160/160S,
Acc. To ANSI B36.19/36.10
O. D.: 6mm to 508mm
W. T.: 0.5mm to 40mm
Length: Max. 20 meters
Delivery conditions: Solution Annealed and Pickled
Inspection: ISO 9001-2000, PED 97/23/EC, ASME, DNV
Applications: For fluid and gas transport, structure and Machining
packing: Seaworthy wooden cases/plywood box/steel framed cases/ simple packaging
Manufacturing method: Cold drawn, hot rolled ,ERW
Surface finish: Anneal/pickling/manual polished/ mechanical polished
Material: TP304/304L/H/LN, TP309S/310S, TP316/316L, TP317/317L, TP321/321H, TP347/347H, TP316Ti, TP904L, N08904, S31803, S32205, S32304, S32750, SAF2205, SAF2304, SAF2507, 1.4301, 1.4306, 1.4401, 1.4404, 1.4833, 1.4845, 1.4571, 1.4438, 1.4541, 1.4550, 1.4539, 1.4462 1.4410, 12X18H10T, 08X18H10T and so on.5) 6) Size:
NPS: 1/8" to 20"
Schedule: 5/5S, 10/10S, 20/20S, 40/40S, 80/80S, 120/120S, 160/160S,
Acc. To ANSI B36.19/36.10
O. D.: 6mm to 508mm
W. T.: 0.5mm to 40mm
Length: Max. 20 meters
Delivery conditions: Solution Annealed and Pickled
Inspection: ISO 9001-2000, PED 97/23/EC, ASME, DNV
Applications: For fluid and gas transport, structure and Machining
packing: Seaworthy wooden cases/plywood box/steel framed cases/ simple packaging
| Grade | Chemical Composition (%) | Mechanical Properties | |||||||||
| C | Mn | P | S | Si | Cr | Ni | Mo | Tensile Strength Mpa min |
Yield Strength Mpa min |
Elongation % |
|
| TP304 | 0.08 | 2.0 | 0.045 | 0.03 | 0.75 | 18.0-20.0 | 8.0-11.0 | / | ≥515 | ≥205 | ≥35 |
| TP304L | 0.035 | 2.0 | 0.045 | 0.03 | 0.75 | 18.0-20.0 | 8.0-13.0 | / | ≥485 | ≥170 | ≥35 |
| TP304H | 0.04-0.10 | 2.0 | 0.045 | 0.03 | 0.75 | 18.0-20.0 | 8.0-11.0 | / | ≥515 | ≥205 | ≥35 |
| TP316 | 0.08 | 2.0 | 0.045 | 0.03 | 0.75 | 16.0-18.0 | 11.0-14.0 | 2.00-3.00 | ≥515 | ≥205 | ≥35 |
| TP316L | 0.035 | 2.0 | 0.045 | 0.03 | 0.75 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | ≥485 | ≥170 | ≥35 |
| TP316H | 0.04-0.10 | 2.0 | 0.045 | 0.03 | 0.75 | 16.0-18.0 | 11.0-14.0 | 2.00-3.00 | ≥515 | ≥205 | ≥35 |
| TP321 | 0.08 | 2.0 | 0.045 | 0.03 | 0.75 | 17.0-19.0 | 9.0-12.0 | / | ≥515 | ≥205 | ≥35 |
| TP347 | 0.08 | 2.0 | 0.04 | 0.03 | 0.75 | 17.0-20.0 | 9.0-13.0 | / | ≥515 | ≥205 | ≥35 |
| TP347H | 0.04-0.10 | 2.0 | 0.04 | 0.03 | 0.75 | 17.0-20.0 | 9.0-13.0 | / | ≥515 | ≥205 | ≥35 |
