Welded ASTM A312 316L ASME B36.19 Stainless Steel Pipe
Key Specifications / Features
Model No.: HX- Carbon Steel Pipe-53 Hits: 22
China Welded ASTM A312 316L ASME B36.19 16IN Stainless Steel Pipe
Request a quote
Share
Tags
Detail Information
Product: stainless steel pipe
Type:welded pipe
Standard & Material: ASTM A312 316L ASME B36.19
Size: 16IN SCH10S
Ends:BE
Application: Used for general corrosive and low or high temperature condition service
Packing:As Your Requirement
Payment Terms: TT, LC, Paypal, West Union, O/A
Delivery Time：7-25 Days after Received the Deposit
Type:welded pipe
Standard & Material: ASTM A312 316L ASME B36.19
Size: 16IN SCH10S
Ends:BE
Application: Used for general corrosive and low or high temperature condition service
Packing:As Your Requirement
Payment Terms: TT, LC, Paypal, West Union, O/A
Delivery Time：7-25 Days after Received the Deposit
| Chemical Compositon | ||||||||
| Steel Grade | Chemical Composition (%) | |||||||
| C | Mn | P | S | Si | Cr | Ni | Mo | |
| TP304 | 0.08 | 2 | 0.045 | 0.03 | 0.75 | 18.0-20.0 | 8.0-11.0 | / |
| TP304L | 0.035 | 2 | 0.045 | 0.03 | 0.75 | 18.0-20.0 | 8.0-13.0 | / |
| TP304H | 0.04-0.10 | 2 | 0.045 | 0.03 | 0.75 | 18.0-20.0 | 8.0-11.0 | / |
| TP316 | 0.08 | 2 | 0.045 | 0.03 | 0.75 | 16.0-18.0 | 11.0-14.0 | 2.00-3.00 |
| TP316L | 0.035 | 2 | 0.045 | 0.03 | 0.75 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 |
| TP316H | 0.04-0.10 | 2 | 0.045 | 0.03 | 0.75 | 16.0-18.0 | 11.0-14.0 | 2.00-3.00 |
| TP321 | 0.08 | 2 | 0.045 | 0.03 | 0.75 | 17.0-19.0 | 9.0-12.0 | / |
| TP347 | 0.08 | 2 | 0.04 | 0.03 | 0.75 | 17.0-20.0 | 9.0-13.0 | / |
| TP347H | 0.04-0.10 | 2 | 0.04 | 0.03 | 0.75 | 17.0-20.0 | 9.0-13.0 | / |
